Type | Twin rigged/Wet Fish/Flyshooter |
Built | 2018, Poland/Netherlands |
Class | BV, Valid until 2028 |
Dimensions | 31,79 x 8,76 x 6,75 |
Tonnage | GT; 373 NT: 120 |
Main Engine | ABC 6 DZC / 749 Kw. New 2018. Cylinder head overhaul 2024 |
Aux Engine | 2 x Mit S6B3, 335 Kw. |
Gearbox | Reintes, WGF 1163 – 8,915:1 |
Harbour gen | John Deer 4045 AFM85, 168 kW |
Machine Equipment | 1 x MDO Fuel Seperator 1 x Fuel Trim pump 2 x Water Hydrofoor – 1 Boiler 120 l 1 bildge pump 1 x General Water pump 1 x Waterpump deckwash 1 Vacuum toilet system – With Collection tank 2 x Atlas Compo Air Pressure system with Air Bottles 1 x (Start) Air dryer |
Deck Equipment | 1 Trawl Winch (Central line( Hydraulic (MS-83 Motor) Cap: 790mtr with 26 mm Wire Max 18,3 tons – 220 BAR 2 (Twinrig) Trawl Winch / Hydraulic (MS-83 Motor) Cap: 790 mtr. x 26 mm wire Max 18,3 ton – 220 BAR 2 Flyshoot winches / Hydraulic ( with Poclain MS-125 pump ) Cap: max. 5.800 mtr. From 40 mm rope 2 x Net Drums ( High in Aftermast ) ( Split Net drums – 4 Motors ) 4 x Poclains Hydraulic motor : MS-83 – 10019 CC cap: 10,8 m3 ( 2600 x 2200 x 500mm ) Max : 12,3 ton. On kern With Flowdrivers in between for a 100% secure split option. 2 x Gilson Winches, 12,6 tons 1 x IRON FIRST CRANE / max. 1.250 kg @ 9 mtr. 1 x Hydraulic driven anchor winch |
Processing | 2 x VCU (Flake) ice machine’s 1 x Fish Elevator to Sorting table. 1 x Sorting Table – Elevator 1 x Fish Collection bench with underside electric belt 2 x Automatic washing machine ( 5 options ) / 2 Electronic Belt on aft for (graded) Prawns to Fish hold 1 x Stainless steel Gutting table with own Venturi wash machine Cooling Fish hold and (Flake) Ice machines 1 x Cooling system : 10,5 Kw. / R-407 2 x Zanotti Cool units 2 x VCU Flake Ice machine’s capacity of 3.000 kg 24 hrs. eachs. |
Electronics | All Modern |
Accommidation | 9 persons, 4 x 2 man cabins, 1 Captain |
